Early Rider Hellion X24 Kids Full Suspension Mountain Bike (MY24/25)

Go big.

Another collaboration with the mighty Lil Shredder, a race ready enduro machine born of necessity on the black runs of Whistler. A bike fast enough, plush enough, and responsive enough to run back to back all summer long. This phenomenal machine is the peak of kids' performance bikes and the history of riders that have played a part of the bikes development is beyond comparison.

The HX24 uses a combination of 6061 and 6066 tubing to give the best possible stiffness to weight ratio. Frame components are fully CNC’d, single pivot suspension kinematics giving predictable and durable performance. Progressive geometry combines with the world's best aluminum frame maker, the HX24 is clean, simple and proven. It’s all hidden in the detail; stealth dropper post ready, ISCG tabs & a 4 bearing pivot.

Out of the box the bike comes setup in the 4 “ travel position, a fantastic and appropriate trail rig. But drop the rear shock mount into the 5” position, and see the headtube slacken by 1.5 degree, bb drop and turn the bike into a descending hooner!

A market leading 1 x11 Shimano clutch equipped drivetrain with a huge gear range. Rapid fire shifters for immediate transitioning, direct mounts cranks, narrow wide chainrings and external bottom bracket for super smooth drive transfer to an immensely capable wheel set. Tubeless ready, double walled rims, CNCd' straight pull hubs on thru axles and running high thread count folding tyres.

Supported by light actuating Shimano hydraulic brakes that provide immediate, powerful braking no matter the conditions and a proven 120mm travel RST fork specifically chosen to complement the geometry of the bike. The Hellion X24 is the bike that showed that kids can do everything that adults can do, if they have the right tools.

Key features

Frame: Butted alloy frame, 100/125mm travel, dropper ready
Fork: RST first air 15, 120mm travel, 15mm thru axle, pm disc mount
Shifter: Shimano SL-M5100-IR, Deore, right,11-speedrapidfire
Brakes: Shimano Deore BL-MT6000, 160mm rotors
Tyres: Vee Crown Gem skinwall 24*2.25" 72 TPI, folding
Weight: 11.5kg w/o pedals

Specifications

Frame: Butted alloy frame, 100/125mm travel, dropper ready
Rear shock: Dnm AO-38RC, 165X38mm rebound adjust, pedal platform
Fork: RST first air 15, 120mm travel, 15mm thru axle, pm disc mount
Steerer: Tube AL6061
Cranks: Samox 150mm direct mount
Axles: Thru axles AL7075, 15mm front, 142 x 12mm rear (1.0P)
Pedals: Sdg slater 90 pedals, black
Bottom bracket: Samox 24mm external cup, sealed cartridge bearing
Rims: 24 X 28H, double walled AL6061, tubeless compatible
Rear hub: CNC'd straight pull AL6061, 12 x 142 (1.0) thru axle
Front hub: CNC'd straight pull AL6061, 15mm thru axle
Chain: KMC X10
Chainring: Samox direct mount steel 30T
Weight: 11.5kg w/o pedals
Shifter: Shimano SL-M5100-IR, Deore, right,11-speedrapidfire
Rear cassette: Shimano CS-M5100-11, Deore, 11-speed 11-51T
Brakes: Shimano Deore BL-MT6000, 160mm rotors
Levers: Shimano Deore BL-M6000
Front tyre: Vee Crown Gem skinwall 24*2.25" 72 TPI, folding
Rear tyre: Vee Crown Gem skinwall 24*2.25" 72 TPI, folding
Headset: Semi integrated, tapered 1 1/8” - 1 1/5" cartridge bearing
Stem: Ritchey OS forged AL6061, 35mm reach
Bars: 640mm Ritchey OS double butted AL6061, 18mm rise
Grips: ER lock on kraton 120mm
Seat post: Ritchey, 30.9mm x 350mm, AL6061
Saddle: Sdg fly jr, black
Seat clamp: Ritchey QR, 34.9mm
Derailleur: Shimano RD-M5100, Deore,sgs 11-speed

Geometry

Wheelbase: 1065mm
Head Angle: 66°
Seat Tube Length: 330mm
Chainstay Length: 425mm
Seat Tube Angle: 70°
Standover Height: 640mm
Top Tube Length: 537mm
Head Tube Length: 127mm
Stack: 552mm
Reach: 335mm
Fork Length: 500mm

View the user manual (PDF)
